Description
Engine Type LH139QMB
Engine Displacement 49.5cc
Cylinders Single cylinder
Cycle Four stroke
Bore and Stroke 39mm x 41.4mm
Cooling Forced air-cooling
Ignition CDI
Rated Power 3.5/7500(hp/rpm)
Rated Torque 3.0/6000(Nm/rpm)
Nominal Dry Weight 172 Lbs
Front Suspension Type Telescopic fork
Rear Suspension Type Unit swing
Front Brake Hydraulic disc
Rear Brake Drum
Seat Height 29.1 in
Wheelbase 47.0 in
Fuel Capacity 1.7 gal
Ground Clearance 3.1 in
Front Tire Size 3.0-10 or 90/90-10
Rear Tire Size 3.0-10 or 90/90-10 M
Minimum Fuel Octane Required 90
Transmission/Gearbox CVT Belt Drive
